Go No Go Gauges

EN50075 Figure 2 Plug Gauge Test Gauges A

7006-27F-1
Go gauge for E14 caps on finished lamps
Purpose: To check the maximum dimensions of the screw thread and dimension T1 minimum of E14 caps on finished lamps.
Testing: When the cap on a finished lamp has been screwed into the gauge as far as it will go, the centre contact shall be co-planar with, or project beyond surface X. “

GET A QUOTE

EN50075 Figure 7 Plug Gauge

Product Description:

Arrangement for compression test

a steel base;

a steel plate;

and a weight of 150N.

EN50075 test devices list:

Serial number Product name Standard
1 Gauge for pin diameter EN50075-Fig1-GO
2 Gauge for pin diameter EN50075-Fig1-NotGO
3 Gauge for interchangeability EN50075-Fig2
4 Standard test finger EN50075-Fig3
5 Gauge for checking impossibility of single-pole insertion of plugs into socket-outlets EN50075-Fig4
6 Apparatus for testing cord retention to the accessory EN50075-Fig5
7 Arrangement for compression test EN50075-Fig7
8 Tumbling barrel EN50075-Fig8
9 Apparatus for abrasion test on insulation sleeves of plug pin EN50075-Fig9
10 Apparatus for compression test for the verification of resistance to heat EN50075-Fig10
