S Style Strain Gauge Load Cell

Introduction

Rated load: 10kg,150kg,200kg,250kg,300kg,500kg,1000kg,2000kg

Feautures: Alloy steel structure; bellows hermetically sealed by laser, nickel plated

waterproof and anticorrosion, suitable for multiform environments; suitable for electronic platform scales, hopper scales, and other electronic weighing devies.

GET A QUOTE
CONTACT US

S Style Strain Gauge Load Cell

Model#BND-CFBLS


Introduction

Rated load: 10kg,150kg,200kg,250kg,300kg,500kg,1000kg,2000kg

Feautures: Alloy steel structure; bellows hermetically sealed by laser, nickel plated

waterproof and anticorrosion, suitable for multiform environments; suitable for electronic platform scales, hopper scales, and other electronic weighing devies.

Parameters:

Model Number

BND-CZL301U

Material

Alloy steel

Precision

C2 & C3

Comprehensive   error(%F.S)

±0.03   & ±0.02

Rated   output(mv/v)

2.0±0.004

Creep(%F.S/30min)

±0.024 & ±0.016

Zero balance(%F.S)

±1.0

Input resistance(Ω)

350±5

Output resistance(Ω)

350±3

Insulation resistance(MΩ)

≥5000(100VDC)

Temp. effect on span(%F.S/10℃)

±0.017& ±0.011

Temp. effect on zero(%F.S/10℃)

±0.023 & ±0.015

Compensated temp. range(℃ )

-10~+40

Use temp. range(℃ )

-20~+55

Excitation voltage(V)

9~12(DC)

Safe overload (%F.S)

150

Ultimate overload (%F.S)

200

Defend grade

IP66
